DTSD1088
DTSD1088 Three Phase CT Meter
Three phase CT-connected smart meter designed for commercial and industrial applications requiring indirect metering. Supports advanced power quality measurement, demand profiling, and multi-tariff billing.
Key Features
- CT-connected for high-current applications
- Four-quadrant energy measurement
- Power quality monitoring (THD, voltage sag/swell)
- Maximum demand recording with reset
- Multi-tariff and TOU billing support
- Load profile recording (configurable intervals)
- RS485 and Ethernet communication
Technical Specifications
| Voltage | 3×230/400V AC |
| Current Range | 1.5(6)A via CT |
| Accuracy Class | Class 0.5S (IEC 62053-22) |
| Frequency | 50Hz / 60Hz |
| Communication | RS485 / Ethernet / NB-IoT |
| Load Profile | Up to 12 channels |
| Display | LCD with backlight, multi-page |
| Standards | IEC 62052-11, IEC 62053-22, IEC 62053-23 |
| Enclosure Rating | IP54 |
Request a Quote for DTSD1088 Three Phase CT Meter
Contact our product specialists for detailed pricing, datasheets, and compliance certificates for the DTSD1088.
